0.8 - 2.5 µm (4 channels) extension to 5 µm
4 readout lines of 1200x12 TDI pixels
15 µm pixel pitch
MCT Technology

Features

  • Versatile Architecture
  • 100% Operability
  • Space Proven Architercure
  • On Board LSTM Mission
  • ROIC Architecture -  Snapshot integration type (IWR & ITR mode) / TDI on-chip (12 stages) /  1 analog output per readout line (Pseudo-differential mode, 2.1V maximum output voltage swing)
Operating Temperature 200K (nominal)

Description

Linear infrared detector for space imaging applications.

LYNRED Linear CAPYORK is a large linear detector specially tailored for earth observation applications from SWIR up to MWIR spectra l range.  Based on LYNRED space proven MCT technology, LYNRED Linear CAPYORK detector, developed in the frame of LSTM mission offers the highest level in terms of performance (100% operability, high frame rate, on-chip TDI…) and versatility (compatible design with staggered/butted configuration, gain selection, integration time adjustment per readout line…).

Documentation

CAPYORK Datasheet
